Product Description
LIGHT SOURCE
▪ LEDs: COB 200W, cool white
▪ Color temp: 6500K
▪ Color rendering index(CRI): Ra>95
▪ LEDs average lifespan: >50,000hrs
▪ Drive mode: constant current
OPTICS
▪ Beam angle: 19°-50°, manual adjustable
▪ Flicker free (refresh rate >100K Hz)
COLORS
▪ Colors: Single color, cool white
EFFECTS
▪ with manual zoom function
▪ Electronic dimmer: 0-100% linear
▪ Electronic strobe: 1-20 flashes/sec
CONTROL AND PROGRAMMING
▪ Control mode: DMX, autorun and Master/Slave
▪ DMX Channels: 1CH/4CH
▪ DMX Data In/Out: XLR 3Pin (XLR 5Pin optional)
BODY
▪ Housing: streching aluminium body
▪ Housing color: black (white optional)
▪ Housing surface treatment: baking finished
POWER SUPPLY
▪ Power consumption: Max. 200W
▪ Auto switching power supply unit
▪ Power supply: AC100V-240V, 50/60Hz (auto-ranging)
COOLING & THERMAL MANAGEMENT
▪ Cooling system: No noise fan (copper tube)
SAFETY DEVICES
▪ Power failure memory
▪ Electronic protection against short circuit
RIGGING
▪ With single mounting yoke
ENVIRONMENT AND PHYSICAL
▪ IP rating: IP20
▪ Environment temp: -20°C-45°C
▪ Dimensions(mm): L662 x W340 x H432 (with yoke)
▪ Net weight: 13.4 kgs
ACCESSORIES
• Gel frame(i.e. filter frame) included
• Gobo holder included
• DMX cable included
• Power input cable included, length 1.2mtr
• Power cable: 0.75mm2, PVC
• Safety cable not included (optional)
• Manual iris not included (optional)
