LMPSZ50-1225A1(CW)B

LED Mini Ellipsoidal Zoom, 60W,13°- 25°,Cool White,IP20,Black Shell

Product Description

ELECTRICAL
Power supply: Electronic auto-ranging
Input voltage range: 100-240 V, 50/60 Hz
Power in/out connector:powerCON in/out
DMX data in/out: 3-pin XLR(5 pin optional)
Power Consumption: 65W

LIGHT SOURCE
Light Source Type: COB 60W, 6500K
LED life expectancy:50,000hrs
CRI: Ra>92
Color Temperature:6500-6800K

OPTICAL SYSTEM
Beam Angle: 13°-25°, manual zoom
Lens Type: HQ glass lens optics
Light ouput (full Bright)@12°: 1071Lux@3mtr; 355Lux@5mtr
Light ouput (full Bright)@25°: 401Lux@3mtr; 139Lux@5mtr

BODY
Body: streching aluminium and iron
Body Color: Black(white optional)
Housing surface treatment: baking finished

CONTROL AND PROGRAMMING
Control Mode: DMX, Master/Slave
Protocols: DMX512
Dmx Channels: 2CH

DYNAMIC EFFECTS
Colour mixing mode: single white
Dimmer: Linear 0~100% electronic dimmer
Strobe/Shutter: 1-20 Hz, electronic
Operating Temperature: -10° / 45°
Flicker: Flicker free operation

PHYSICAL
Control Connection: 3p in/out
Power Connection: PowerCON in/out
Cooling: forced air convection, with 1 slient fan

DIMENSIONS
Product Weight:4.3 kgs
Fixture size (WxHxD): L390 x W183 x H160 mm(with yoke)

LISTINGS
Certification: CE
Environment: IP20

INCLUDED ACCESSORIES
Gel frame(i.e. filter frame) included
Gobo holder included
Power input cable included, length 1.0mtr (0.75mm2, PVC )

OPTIONAL ACCESSORIES
DMX cable not included (optional)
Safety cable not included (optional)

KEY FEATURES
Sharp, clean beam
Flat, even field of light
High-efficiency optics
Noiseless operation
Simple and complex DMX channel
MASTER / SLAVE mode

Ideal for Theatre, Church, Mobile DJs, Clubs, Bars, Retail Stores and Promotional Events.
