Product Description
LIGHT SOURCE
LEDs: COB 20W, warm white
Color temp: 3000K
Color rendering index(CRI): Ra>93
LEDs average lifespan: >50,000hrs
Drive mode: constant current
OPTICS
Beam angle: 19°(14°/26°/36°optional)
Flicker free (refresh rate >100K Hz)
COLORS
Single color, Warm White （Cool White optional)
EFFECTS
16 bit smooth dimming
Electronic dimmer: 0-100% linear
Electronic strobe: 1-25 flashes/sec.
CONTROL AND PROGRAMMING
DMX Channel: 2CH
PAN-TILT
Tilt: -135º～+135º
BODY
Housing: Die-Cast Aluminum
Housing color: black (white optional)
Housing surface treatment: baking finished
POWER SUPPLY
Power consumption: Max. 22W
Auto switching power supply unit
Power supply: AC100V-240V, 50/60Hz (auto-ranging)
COOLING & THERMAL MANAGEMENT
NO fan, heatsinks in aluminum for LED source
SAFETY DEVICES
Power failure memory
Electronic protection against short circuit
RIGGING
With single mounting yoke
ENVIRONMENT AND PHYSICAL
IP rating: IP20
Environment temp: -20°C-45°C
Dimensions(mm): L261 x W158 x H263 (with yoke)
Net weight: 1.1 kgs
ACCESSORIES
Gel frame(i.e. filter frame) included
Gobo holder included
Manual iris not included (optional)
Power input cable included, length 1.0mtr
Power cable: 0.75mm2, PVC
DMX cable included
Safety cable not included (optional)
