Product Description
OPTICAL
▪ Light Source: 1 * 80W COB LED (CW), 50,000 hours life expectancy
▪ CRI: 95
▪ Beam Angle: 15°-30°
▪ Power consumption: 80W
▪ Color temperature: 5600k
DYNAMIC EFFECTS
▪ Dimming Frequency: 500HZ – 25000HZ optional
▪ Strobe: 1-25times/sec
▪ Dim Modes: 4
▪ Dimming Frequency: 500HZ – 25000HZ optional
▪ 4 Metal spot cutting slots
▪ 0-100% Smooth linear dimmer
CONSTRUCTION / PHYSICAL
▪ Dimensions: 303x202x280 mm
▪ Weight (single unit):4.0 kg
▪ Exterior Color: Black
▪ Housing Material: Aluminum die-cast
CONNECTIONS
▪ Power Connection: Waterproof power cable
▪ Cable Length (power): 1M
▪ Signal Connection: 3-Pin XLR connectors IN/OUT
CONTROL
▪ Control Protocol: RDM/DMX512, master-slave, or static mode
▪ DMX Channels: 1/3CH
ELECTRICAL
▪ Input Voltage: 100 to 240 VAC, 50/60 Hz (auto-ranging)
WORK ENVIROMENT
▪ Maximum ambient temperature (Ta max.): 40° C
▪ Minimum ambient temperature (Ta min.): 5° C
COOLING & THERMAL MANAGEMENT
▪ Fan-less no noise cooling system
QUALIFICATIONS
▪ IP Rating: IP65
WHAT’S INCLUDED
▪ Gobo and gobo holder: optional
▪ Color Frame: optional
